New photos coming soon!
Mebor Purchase Order
Year 2017
100 Kw, 460 volt three phase, 60 hz, 170 amps
The saw was ordered with the following options:
Extend cutting length to 24 ft ($9,565.00)
Upgrade control system and set works ($9,490.00)
RCL 1000 live roll conveyor with two sets of sweep chains
($32,900.00)
38 ft x 40" built in dust waste conveyor with leg
extensions ($23,700.00)
*Total price new in 2017 ($239,655.00)*
Productivity: upto 35 m3/8hrs
Max log diameter: 1000-1200 mm (39.3" to 47.2")
Max cutting width: 1000-1170 mm (39.3" to 46")
Max log length 7315 mm (288") 24ft
Diameter of saw wheels 1200 mm (47.2")
Width of saw wheels 120 mm (4.72")
Blade length 7750 mm (305.1")
Max blade width 140 mm (5.51")
Blade thickness 1.2-1.3 mm (0.0472"-0.0512")
Machine weight 12,800 Kg (28,219 Lbs)
